Our most powerful scalable passive fire protection, designed for smaller spaces

MAUS STIXX PRO 10

Our most powerful scalable passive fire protection, designed for smaller spaces

FLOODING

FLOODING

Once activated it will release 100% of it’s content.

FAST

FAST

Activation at very low temperature 170 °C.

SYSTEM

SYSTEM

No complex system. No electric cables. No batteries. No pressure.

NON-TOXIC

NON-TOXIC

The potassium formula is 100% non-toxic & environmentally friendly.

MAINTENANCE

MAINTENANCE

Maintenance free during its 5 year life span.

AWARD WINNING

AWARD WINNING

MAUS Stixx PRO series has won several awards in Europe.

About the product

Innovative fire suppressor for medium to larger spaces – sanitation-free, no impact on existing infrastructure, easy to install, and fully passive protection for 5 years.


The MAUS Stixx PRO 10 is designed for medium to larger enclosures and can be serially connected to quickly reach a potential fire source. The combination of compact design and high capacity makes the MAUS Stixx PRO series a unique fire suppression solution on the market.


This automatic unit features a built-in heat detecting cable on the top, which activates the suppression when exposed to fire or when the unit reaches 170 °C. A single Stixx PRO 10 protects a space of 1.0 m³ and can be mounted using the adhesive tape on the back or the screw holes on the front.


The extinguishing agent is released through the unit’s ports, rapidly filling the enclosure to extinguish the fire. For a larger detection area, additional heat detecting cables can be connected using the included metal cylinders to the ports on the sides. With cable clips, the cable can be easily secured inside the enclosure for optimal detection. For larger spaces, multiple units can be connected in series for increased coverage (see MULTIPLE UNITS illustration).

About the product

CategoryDetails
Name of ProductMAUS Stixx PRO 10
Article Number1370-1
DescriptionFire suppression unit with a capacity for spaces up to 1 m³.
ApplicationElectrical enclosures, Switchgears, Server rooms, Engine compartments, Motorhomes.
AdvantagesSmall size, Maintenance-free, Low temperature activation, No damage to hardware or electronics.
SpecificationValue
EAN7350015530256
Dimensions75 x 75 x 22.5 mm
Weight200 g.
Product life5 years (6 years shelf life)
Discharge time≤5s
Protected Area1 m³
Activation Temperature170°C ± 10°C
CertificationsCE 2829
Operational Temperature-30°C to 70°C
Crimping Tool

Crimping Tool

4406-1 Rectifier Battery Backup

HDC Cable

4405-1 Rectifier

Clips

4402-1 Manual Call Point

Metal Cylinders

CategoryDetails
Name of ProductMAUS Stixx PRO 10
Article Number1370-1
DescriptionFire suppression unit with a capacity for spaces up to 1 m³.
ApplicationElectrical enclosures, Switchgears, Server rooms, Engine compartments, Motorhomes.
AdvantagesSmall size, Maintenance-free, Low temperature activation, No damage to hardware or electronics.
SpecificationValue
EAN7350015530256
Dimensions75 x 75 x 22.5 mm
Weight200 g.
Product life5 years (6 years shelf life)
Discharge time≤5s
Protected Area1 m³
Activation Temperature170°C ± 10°C
CertificationsCE 2829
Operational Temperature-30°C to 70°C
Crimping Tool

Crimping Tool

4406-1 Rectifier Battery Backup

HDC Cable

4405-1 Rectifier

Clips

4402-1 Manual Call Point

Metal Cylinders

Download Catalogue

Explore our industrial solutions — download the MAUS Industry Brochure for more details.
